Product Detail
The G6 Metal Robot Arm Mechanical Claw Gripper is a reliable and sturdy clamp kit designed for robotics enthusiasts and professionals.
Made from high-strength aluminum alloy, this claw ensures both durability and lightweight handling.
With a wide 86mm maximum separation and smooth servo-powered grip, it is perfect for handling small to medium-sized objects in robotic projects.
Whether you are building a robotic arm for education, hobby, or automation, this gripper offers a simple yet effective solution.
Features:
- Material: Hard aluminum alloy
- Maximum angular separation: 86mm
- Lightweight, only ~40g (without servo)
- Compatible with G6 Robot Arm Kit setups
- Compact overall length of 83mm
- Easy integration with servo motor
Applications:
- DIY robotic arm projects
- Educational robotics kits
- Automation and gripping systems
- Hobby robotics and prototyping
- Pick-and-place mechanisms
Technical Specifications:
| Specification | Details |
|---|---|
| Model | G6 Robot Arm Kit |
| Material | Hard Aluminum Alloy |
| Weight | About 40g (without servo) |
| Maximum Angular Separation | 86mm |
| Overall Length | 83mm (paw closed) |
| Overall Width (Open) | 150mm |
| Overall Width (Closed) | 55mm |
| Overall Thickness | 54mm (with servo paws) |
| Included Servo | Yes |
Please allow 3% measuring deviation.
Package:
-
1x Robot Arm Gripper
-
1x Servo Motor
Documentations:
How to Use (DIY Mini Blog):
Building with the G6 Robot Arm Gripper is simple. Start by attaching the servo motor to the claw base using the included screws.
Once secured, connect the servo to your robot arm structure. Plug the servo motor into your controller or driver board, then test its movement.
Adjust the servo angles to calibrate the claw’s opening and closing range. Finally, mount the entire assembly on your robotic arm and start experimenting with picking and placing objects.
FAQ:
- Q1: Is the servo included in the package?
A1: Yes, the kit includes one servo motor. - Q2: Can I use it with Arduino-based robotic arms?
A2: Yes, it is fully compatible with Arduino and other microcontroller platforms. - Q3: What is the maximum object size it can grip?
A3: Up to 86mm in width. - Q4: Is the claw strong enough for heavy objects?
A4: It is designed for lightweight to medium objects, not for very heavy loads. - Q5: Can I replace the servo with another model?
A5: Yes, as long as it fits the mounting dimensions.
